cellular cardboard shredder, coated paper crusher, single shaft shredder

cellular cardboard shredder, coated paper crusher, single shaft shredder

Model No.︰S

Brand Name︰United Tech

Country of Origin︰China

Unit Price︰-

Minimum Order︰1 pc

Inquire Now

Product Description

Our single shaft shredder ( Zibo United Tech Machinery Co., Ltd. ) have a wide application in the scrap paper recycling:

Applications including:

cellular cardboard, office paper, whiteboard paper, white cardboard, advertising film paper, kraft, corrugated paper, box board paper, PE coated paper, trademark paper, label paper, parchment, chip board paper, yellow straw paper, waste newspaper, coated paper, news-printing paper, garbled paper, pulp, composite paper, cellular paper, waste paper board, paper tray, life paper, and paper cup, etc, various waste paper shredding and recycling. The output size can be adjusted according to clients' requirements.

1. Single Shaft Shredder Introduction:

Single shaft shredder - Zibo United Tech Machinery Co., Ltd. is available to recycle wide range of material. It is an ideal machine for plastic, paper, wood, fiber, rubber, organic waste a wide variety of non-metallic materials. As per our customer’s requirements, such as the input size of materials. Capacity and the final output size etc. We could work out a suitable proposal for our clients. After being shredder by the machine, the output material could be used directly or go int to the next step of size reduction.
With the function of Siemens microcomputer control system, it is possible to control automatically start, stop. Automatic reverse sensors to protect the machine against over loading and jamming. The output capability typically range between 300kg/hr –5,000kg/hr+ depending on the different model and different materials.
2. Cutting Principle about the Single Shaft Shredder:

The cutting part of the Single shaft shredder - Zibo United Tech Machinery Co., Ltd.  including the rotor, rotor blade, counter blade and the screen. The minimum mounting clearances between the rotor blade and counter blade is 0.1mm. The motor drive the rotor by high speed rotating trough the speed reducer, therefore the rotor blade cutting the counter blade. After one cutting, the materials will be discharged if its size smaller the screen mesh size. Or the material will be double or more cutting, until the size is smaller than the screen holes.
3. Single Shaft Shredder Advantage:

* Detachable Rotor Blade, easy disassemble and installation, and simple maintenance.
* Automatic Feeder, increase produce efficiency.
* Quick change Screen for accurate particle size control.
* Shock Absorbing Gearbox reduces stress on Drive components.
* Integrated Rotor, assured the cutter clearance between the Rotor Blade and the Counter Blade.
* Enclosed Bearing protection design, waterproof and dustproof, extend the bearing work life.
* PLC Control System, automatic reverse sensor to protect the machine against over loading and jamming.
* Provide the Rotor Cooler System against the low melting materials, prevent the materials burning while the temperature higher.

Single shaft shredder - Zibo United Tech Machinery Co., Ltd.

4. Single Shaft Shredder Applications:

Plastic: Film; Jumbo Bag; PET Bottle; Plastic Barriers; Plastic Pipe; Plastic Boards
Hard Plastic: Plastic Lump (Purgings); Fiber, High Strength Engineering Plastics ( ABS, PC, PPS, etc.)
Wood: Timber; Tree Root; Wood Pallets; Wood Package, etc.
Paper:
Industrial Solid Waste: Cable; Light Metal, like Aluminum Can, Aluminum Scrap, etc.

White Goods, like TV Shell, Washing Machine Shell, Refrigerator Body Shell, Computer Shell, Circuit Board, etc. Solid Waste, like Household Garbage, Medicinal Waste, Industrial Waste.

Single shaft shredder - Zibo United Tech Machinery Co., Ltd.
What about the quality of your products?

1. we have a special training for each worker.

2. we use China famous brand spare parts to cast the machine.

3. have a trial test run before delivery the machine out of the factory.

How about the shipping and package?

1. we arrange shipment usually according to your special requirements.

2. Usually plywood package. Or according to clients's requirements.

How to get a suitable machine?

1. what is the raw material

2. the dimension of the input material and outpout material

3. the capacity,and power condition.

Tell me those data, we can help you choose the Waste type Shredder for you.

Please feel free to contact me any time with any questions.

We are waiting for you!

Our service:

(1) Your inquiry related to our products or prices will be replied in 12hours.
(2) Our engineer will make machine placement chart according to client
’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.

Our email: info@utshredder.com

Payment Terms︰ TT, LC

Product Image
